Online High Frequency
Production Introduction
This series UPS applies CPU intergrated control technology, which allows UPS to response prometly and accurately when power outage, high or low voltage, surge, transient or spike occurs while its protection port provides protection for special external devices, such as printers and so on. It possess automatic startup function,automatic voltage regulation function and a wide range of input voltage, so it is applicable to all kinds
of electric power environment. In addition, its design is humanized and elegant with LED or LCD display, those are tow alternatives.
Model | PT-10KL | |||||||||
Capacity | 10000VA/9000W | |||||||||
INPUT | ||||||||||
Frequency Range | 46-54Hz same as AC(AC mode) | |||||||||
Phase | 3 phases with dual wires+earth wire | |||||||||
OUTPUT | ||||||||||
Voltage | 220VAC±2%VAC | |||||||||
Frequency Range | 50-60Hz(Automatic sensing) (AC mode) | |||||||||
220V:50±0.2HZ(DC mode) | ||||||||||
Currrent crest factor | 3:1 | |||||||||
Wave Form | Pure Sine Wave | |||||||||
Battery | ||||||||||
Capacity of battery | --------- | |||||||||
External Battery | 192VDC | |||||||||
Transfer time | 0ms | |||||||||
PHYSICAL | ||||||||||
Dimension(mm) | 500*248*616 | |||||||||
Net weight(kg) | 27 | |||||||||
Management | ||||||||||
Interface | RS232,Interlling Slot Selectable |
