Place of Origin:
China
Brand Name:
G-Tech
Certification:
CE ROHS
Model Number:
GBS
Lithium ion phosphate battery LFP 12V 50Ah LiFePO4 Battery
Model | GBS-LFP50Ah-B | GBS-LF50Ah-D |
Rated Capacity | 50Ah | 50Ah |
Nominal Voltage | 3.2V | 3.2V |
Internal Impedance | ≤0.6mΩ | ≤0.6mΩ |
Standard Charge | 0.25C | 0.25C |
Quick-arting Charge | 1.0C | 1.0C |
Charge cut off voltage | 3.55V | 3.55V |
Standard Discharge | 0.5C | 0.5C |
Maximum continuous discharge | 3.0C | 3.0C |
Instantaneneous Discharege | 5C | 5C |
End of Dischage | 2.5V | 2.5V |
Work temperature | -20~65℃ | -20~65℃ |
Cycle life(times) | >3000CYCLES(0.5C) | >3000CYCLES(0.5C) |
Weight(kg) | 1.7±0.1kg | 1.2±0.1kg |
Dimensions(mm) | 126*46*206±1mm | 126*28*216±1mm |
Safety Advantage
Air vent with double protection functions ensures safety
The World's first controllable air vent with double protection functions is a patented product. It exhausts and opens automatically in one-way mode at different pressure.
Good insulation and lightning resistance in the wild
Plastic shell has good insulations.Cells can be assembled into a DC-high voltage battery pack directly. Insulation ability is not affected by air humidity.Good anti-lightning performance without grounding.Not easy to generate static electricity and cause accidents due to friction generated by electric sparks.
Decompression design in special circumstances
Plasitic shell has low melting point(170℃).It melts and makes decompression automatically in the extreme conditions to ensure.
FAQ
1. When will you ship the products when paymnet is done?
Trial order is 3-7 work days,formal order 7-20 work days.
2. Is the sample available ?
Yes, but it is charged.
3. Can I get a lower price if I order large quantities?
Yes.
4. Are you a factory ?
Yes, we are the manufacturer of GBS LiFePO4 battery.
5. Why does it seem your price little higher than other factories?
We always supply High-Quality products & High-Stand service to our clients.
