Alumium Shell Lithium Iron Phosphate Battery Pack 24V 100Ah 3 Years Warranty

Alumium Shell Lithium Iron Phosphate Battery Pack 24V 100Ah 3 Years Warranty

lithium iron phosphate battery pack

lithium fe po4 battery

Brand Name:

G-Tech

Certification:

CE ROHS

Contact Us
Request A Quote
Product Details
Place Of Origin:
China
Model Number:
GT-FP24100T
Application:
EV, Telecom, Solar Energy
Warranty:
3 Years
Battery Type:
Lithium Battery
Material:
Lifepo4 With Alumium Shell
Cycle Life:
≥3000times
Product Name:
Alumium Shell Lithium Iron Phosphate Battery Pack 24V 100Ah 3 Years Warranty
Payment & Shipping Terms
Minimum Order Quantity
10pcs
Price
Negotiation
Packaging Details
Carton packing
Delivery Time
7-25workdays
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100000pcs
Product Description

Lithium ion phosphate battery LFP 24V 100Ah LiFePO4 Battery

24V 100Ah LiFePO4 Battery Pack Good Cycle Life Time For Solar Energy Off-grid photovoltaic energy storage system



Model GT-FP24100T
Rated Capacity 100Ah
Nominal Voltage 24V
Work temperature -20~65℃
Cycle life(times) >3000CYCLES(0.5C)
Weight(kg) 29.50 kg
Dimensions(mm) 482*300*133mm



Safety Advantage

Air vent with double protection functions ensures safety

The World's first controllable air vent with double protection functions is a patented product. It exhausts and opens automatically in one-way mode at different pressure.



Good insulation and lightning resistance in the wild

Plastic shell has good insulations.Cells can be assembled into a DC-high voltage battery pack directly. Insulation ability is not affected by air humidity.Good anti-lightning performance without grounding.Not easy to generate static electricity and cause accidents due to friction generated by electric sparks.



Decompression design in special circumstances

Plasitic shell has low melting point(170℃).It melts and makes decompression automatically in the extreme conditions to ensure.



Basic Performance

1. Output with high efficiency: Standard discharge current is 0.3C-0.8C, instant impulse discharge current is 10C for 10 seconds.



2. Good performance under high temperature, it could work under 65°C temperature.The battery structure is safe and good.



3. Good performance under low temperature.discharge capacity decreases to over 78% under 0°C and discharge capacity decreases to over 70% under -20°C.



4. Good safety performance:When the pressure inside the battery is too large, the one-way safety valve will release gas and heat to make sure battery perform well. When the internal pressure reaches a certain level, the valve will be open immediately which can protect the battery from burning and explosion.



5. Good cycle life time, the discharge capacity is still over 80% after 2000 cycle times of single cell(80%DOD).



6. It can fast charging. It could be charged to 80% within 20 minutes and charged full with 2-3h.



7. Low cost.



8. No pollution during manufacture and usage.
