Alumium 100Ah 48V Lifepo4 Lithium Iron Phosphate Battery

Alumium 100Ah 48V Lifepo4 Lithium Iron Phosphate Battery

Lifepo4 Lithium Iron Phosphate Battery

100Ah Lithium Iron Phosphate Battery

48V Lifepo4 Lithium Battery

Brand Name:

G-Tech

Certification:

CE, ISO9001, UL, IEC

Model Number:

GBSFP

Contact Us
Request A Quote
Product Details
Place Of Origin:
China
Application:
Solar Inverter, Telecom, Solar Energy, Back Up Power
Warranty:
2 Years
Battery Type:
Lithium Battery
Material:
Lifepo4 With Alumium Shell
Product Name:
Lithium Iron Phosphate Battery, Safe And Reliable, Long Cycle Life And Replacement Period 48V
Payment & Shipping Terms
Minimum Order Quantity
1pcs
Price
Negotiation
Packaging Details
Carton packing
Delivery Time
7-25workdays
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100000pcs
Product Description

Alumium Shell Lithium Iron Phosphate Battery Pack Solar Inverter Battery 2 Years Warranty Back up LiFePO4 Battery

48V 100Ah LiFePO4 Battery Pack Good Cycle Life Time For Solar Energy Off-grid photovoltaic energy storage system



Model GBS-FP48100T
Rated Capacity 100Ah
Nominal Voltage 48V
Work temperature -20~65℃
Cycle life(times) >3000CYCLES(0.5C)
Weight(kg) 55 kg
Dimensions(mm) 440*480*250mm



Product basic parameters:

Specification

GBSFP48100T
Battery type
Folding lithium iron phosphate battery
Rated voltage
48V
Rated capacity
100Ah
Cell specification
3.2V/100Ah
Mode of battery
pack
16 pieces of single cells + BMS + rack or universal box of iron frame
Dimension of
battery pack
Width 440× depth 480× height 250(mm)
weight
55.0 kg
Working
-20~65℃



Safety Advantage

Air vent with double protection functions ensures safety

The World's first controllable air vent with double protection functions is a patented product. It exhausts and opens automatically in one-way mode at different pressure.



Good insulation and lightning resistance in the wild

Plastic shell has good insulations.Cells can be assembled into a DC-high voltage battery pack directly. Insulation ability is not affected by air humidity.Good anti-lightning performance without grounding.Not easy to generate static electricity and cause accidents due to friction generated by electric sparks.



Decompression design in special circumstances

Plasitic shell has low melting point(170℃).It melts and makes decompression automatically in the extreme conditions to ensure.



Basic Performance



1. Output with high efficiency: Standard discharge current is 0.3C-0.8C, instant impulse discharge current is 10C for 10 seconds.



2. Good performance under high temperature, it could work under 65°C temperature.The battery structure is safe and good.



3. Good performance under low temperature.discharge capacity decreases to over 78% under 0°C and discharge capacity decreases to over 70% under -20°C.



4. Good safety performance:When the pressure inside the battery is too large, the one-way safety valve will release gas and heat to make sure battery perform well. When the internal pressure reaches a certain level, the valve will be open immediately which can protect the battery from burning and explosion.



5. Good cycle life time, the discharge capacity is still over 80% after 2000 cycle times of single cell(80%DOD).



6. It can fast charging. It could be charged to 80% within 20 minutes and charged full with 2-3h.



7. Low cost.



8. No pollution during manufacture and usage.
