Place of Origin:
China
Brand Name:
OEM
Certification:
CE, ROHS
Model Number:
500/650/850/1000/1200/1500VA
| Fields of application |
Suitable for the PC,router,POS machine communication processor,industrial products which for the enterprises,government,scientific research,traffic,national defense,information and education industries.
| Specifications |
| Model | U-650 | U-850 | U-1000 |
| Input | |||
| Input Voltage range | 165 -275 Vac | ||
| Input Frequency Range | 65/45Hz | ||
| Output | |||
| Output Voltage | 230Vac | ||
| Output voltage range | 198-242Vac | ||
| Output frequency | 65/45Hz | ||
| Output wave form | PWM | ||
| Battery | |||
| Battery Rating | 12V/7Ah | 12V/9Ah | 12V/9Ah |
| Charging Period | 4-6 hours recover to 90% capacity | ||
| Socket | Universal/Intalian/American/European | ||
| Protection | |||
| Full Protection | Low voltage & overload & short circuit protection | ||
| Physical | |||
| Net weight (KG) | 4.8kgs | 5.6kgs | 6.4kgs |
| Unit Dimension mm | 280 * 245 * 130 mm | ||
| Environment | |||
| Environment of performance | temperature 0~40 degree, humidity 20%~90% | ||
| Noise level | Less than 40dB | ||
| Performance Characteristics |
Factory Profile:
G-tech Power Co., Ltd. was established in 2002, located at Foshan, Guangdong province. We are a professional manufacturer of high quality UPS (Uninterruptible Power Systems) in China. We specialize in developing, manufacturing and operating the most reliable, manageable and the safest UPS, inverter and AVR (voltage regulator) products.
The factory covers a working area of nearly 20,000 square meters, has more than 500 professional staff (including 30 R&D personnel) and 33 sets of fully automatic SMT lines, more than 10 sets of automatic insertion equipment, ICT PCB testing equipment, ATE automatic testing center and aging workshop for all products.
OEM services are provided for customers in many areas, such as South America, Europe, Russia, India, Africa and some other countries and regions. We are always qualifying ourselves in order to meet the requirements of customers, and we gain more repeat orders and admiration from them.
