AGM Separator 6AH UPS VRLA Regulated Lead Acid Battery

AGM Separator 6AH UPS VRLA Regulated Lead Acid Battery

UPS VRLA Regulated Lead Acid Battery

6AH VRLA Regulated Lead Acid Battery

AGM Separator Lead Acid Battery

Place of Origin:

China

Brand Name:

G-Tech power

Certification:

CE and ROHS

Model Number:

GT12

Contact Us
Request A Quote
Product Details
Voltage:
12V
Sealed Type:
Sealed
Terminal:
Terminal F1/F2
Warranty:
1-3years
Application:
UPS,Solar System,Street Light,Telecommunication
Product Name:
VRLA Regulated Lead Acid Battery Lead Acid Storage Battery Deep Cycle Lead Acid Battery
Payment & Shipping Terms
Minimum Order Quantity
100
Price
Negotiation
Packaging Details
carton
Delivery Time
30 days
Payment Terms
T/T, Western Union, L/C
Supply Ability
50,000pcs/day
Product Description

AGM Battery for Solar power systems, UPS systems, Telecommunications equipment Access control devices

VRLA Regulated Lead Acid Battery lead acid storage battery deep cycle lead acid battery
Features:
Structure: compact design, shorter internal connectors between cells, thus low internal resistance
Plate: Pasted flat type, with patent formula of AM
Terminal: Two or more types terminals are convenient for selection
Vent system: Gas can be vented through flame arrester
Separator: Using improved AGM separator, make lower resistance higher assembling pressure to increase cycle life
Battery case: Made of high strength ABS and UL94-V0 is optional
Terminal sealing: Double sealing technics(mechanical+epoxy gule)

Application:
  • Solar power systems

  • UPS systems

  • Telecommunications equipment

  • Access control devices

  • Electronic toys

  • Electronic equipment require memory protecting

Features:
  • 12 years design life, EUROBAT specification long life

  • Absorbent Glass Mat (AGM) technology

  • Extremely high cycle life and float life performance

  • Wide range of operating temperature -20℃ to +50℃

  • Delivered ready for use at 100% of its nominal capacity

  • Easy for installation, maintenance free operation

  • Shock resistant ABS flame retardant container and lid

  • UL, CE, ISO9001 recognized component

  • Non-hazardous cargo for ground, sea and air transport

  • Computer designed lead, calcium tin alloy grid for high power density

Specification
Series Model Capacity Weight Terminal Size(L*W*H)
GEL Series GT12-26G 26 8.1 F13(M5) 166*175*125(125)
GEL Series GT2-100G 100 5.6 F10(M8) 171*72*206(206)
GEL Series GT6-100G 100 16.5 F14(M8) 194*170*205(210)
GEL Series GT6-150G 150 23.5 F12(M8) 260*180*247(252)
GEL Series GT6-180G 180 26.5 F12(M8) 306*168*222(227)
GEL Series GT6-200G 200 29 F14(M8) 322*177.5*226(247)
GEL Series GT6-200SG 200 30 F12(M8) 260*180*247(252)
GEL Series GT6-225G 225 32 F14(M8) 322*177.5*226(247)
GEL Series GT6-225SG 225 32 F14(M8) 243*187.5*275(275)
GEL Series GT6-280G 280 41.7 F14(M8) 295*178*346(364)
GEL Series GT6-310G 310 44.5 F14(M8) 295*178*346(364)
GEL Series GT6-335G 335 45.5 F14(M8) 295*178*346(364)
GEL Series GT12-33G 33 10.2 F11(M6) 195*130*159(180)
GEL Series GT12-40G 40 13.2 F11(M6) 198*166*171(171)
GEL Series GT12-55G 55 17 F11(M6) 229*138*210(235)
GEL Series GT12-65G 65 21 F11(M6) 350*167*180(183)
GEL Series GT12-70G 70 22.5 F11(M6) 350*167*180(183)
GEL Series GT12-60G 60 20.5 F11(M6) 260*169*210(235)
GEL Series GT12-70SG 70 21.5 F11(M6) 260*169*210(235)
GEL Series GT12-75G 75 23.5 F11(M6) 260*169*210(235)
GEL Series GT12-75SG 75 22.5 F11(M6) 350*167*180(183)
GEL Series GT12-80G 80 23.5 F11(M6) 260*169*210(235)
GEL Series GT12-80SG 80 24 F12(M8) 328*172*222(222)
GEL Series GT12-85G 85 26 F12(M8) 306.5*168.5*210(235)
GEL Series GT12-90G 90 28.5 F12(M8) 306.5*168.5*210(235)
GEL Series GT12-100G 100 30 F12(M8) 328*172*222(222)
GEL Series GT12-120G 120 35.5 F12(M8) 407*177*225(225)
GEL Series GT12-134G 134 41.5 F12(M8) 340*173*280(285)
GEL Series GT12-145G 145 44 F12(M8) 340*173*280(285)
GEL Series GT12-150G 150 44.5 F12(M8) 483*170*240(240)
GEL Series GT12-160SG 160 48 F12(M8) 483*170*240(240)
GEL Series GT12-160G 160 50 F12(M8) 530*209*214(219)
GEL Series GT12-180G 180 53 F12(M8) 530*209*214(219)
GEL Series GT12-200G 200 60 F10(M8) 522*240*219(240)
GEL Series GT12-225G 225 65 F10(M8) 522*240*219(240)
GEL Series GT12-230G 230 67 F12(M8) 521*269*203(208)
GEL Series GT12-260G 260 74 F14(M8) 520*268*220(225)
GEL Series GT2-200G 200 14 F10(M8) 171*111*366(366)
GEL Series GT2-250G 250 17.5 F10(M8) 171*150*365(365)
GEL Series GT2-300G 300 19 F10(M8) 171*150*365(365)
GEL Series GT2-350G 350 24.5 F10(M8) 211*176*329(367)
GEL Series GT2-400G 400 26 F10(M8) 211*176*329(367)
GEL Series GT2-450G 450 29 F10(M8) 211*176*329(367)
GEL Series GT2-500G 500 30.5 F10(M8) 242*172*329(366)
GEL Series GT2-600G 600 37 F10(M8) 302*175*328(365)
GEL Series GT2-650G 650 40 F10(M8) 302*175*328(365)
GEL Series GT2-750G 750 46 F10(M8) 411*175*327(368)
GEL Series GT2-800G 800 50 F10(M8) 411*175*327(368)
GEL Series GT2-1000G 1000 62 F10(M8) 479*175*327(368)
GEL Series GT2-1200G 1200 74 F10(M8) 479*175*327(368)
GEL Series GT2-1500G 1500 96 F10(M8) 401*352*338(383)
GEL Series GT2-2000G 2000 126.5 F10(M8) 490*349*338(383)
GEL Series GT2-2500G 2500 171 F10(M8) 712*351*338(383)
GEL Series GT2-3000G 3000 193 F10(M8) 712*351*338(383)
