Backup Power Supply LiFePO4 Battery Pack Lithium Iron Phosphate Cell

  • Backup Power Supply LiFePO4 Battery Pack Lithium Iron Phosphate Cell
Place of Origin China
Brand Name OEM
Certification CE, UN38.3, MSDS
Model Number LFP24-100
Minimum Order Quantity 1
Price Negotiable
Packaging Details Carton, pallet
Delivery Time 7-10 working days
Payment Terms L/C, D/A, D/P, T/T, Western Union
Supply Ability 5000pcs per month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

WeChat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Battery Type LiFePO4 Max Discharge Current 100A
Cycle Life 5000 Times Capacity 100Ah
Warranty 5 Year Max Charge Current 100A
Highlight

Backup LiFePO4 Battery Pack

,

Phosphate Cell LiFePO4 Battery Pack

,

Backup Lithium Iron Phosphate Cell
Leave a Message
Product Description

50AH 100AH Lithium LiFePO4 Rack Mount Battery Wholesale

25.6V 100AH Lifepo4 Battery Pack, lifepo4 battery pack supplier

Product Description:

Smart LFP series LiFePO4 battery is a high-tech product developed for the requirements of new backup power supply and household renewable energy storage. Built-in intelligent BMS to protect the battery pack at any time and prolong its service life, modular design enables parallel installation for larger power back up. All of our batteries use A grade cells, can communicate with mainstream inverter brands.

Backup Power Supply LiFePO4 Battery Pack Lithium Iron Phosphate Cell 0

Features:



1. High Capacity



2. Long Cycle Life



3. High Discharge Rate



4. High Safety and Reliability



5. Lightweight and Compact



Technical Parameters:

MODEL # LFP 24-100 LFP 48-50 LFP 48-100
SPECIFICATION
Battery Type LiFePO4 LiFePO4 LiFePO4
Battery Model 25.6V100AH 51.2V50AH 51.2V100AH
Nominal Capacity(25℃,0.2C)WH 2560Wh 2560Wh 5120Wh
Adjustable working voltage(Vdc) 22.4～29.2V 44.8～58.4V 44.8～58.4V
Folat Charge Voltage(Vdc) 28V 56V 56V
Max.Continuous discharge current(A) 100 100 100
Max.pulse discharge current(A) 150A 1Sec. 100A 1Sec. 150A 1Sec.
Max.Continuous charge current(A) 100 50 100
Cycle life(+25℃ 0.2C 80% DOD) ＞5000 Cycles ＞5000 Cycles ＞5000 Cycles
Cell Equalizer Current(A 0.1～5A Max.(optional) 0.1～5A Max.(optional) 0.1～5A Max.(optional)
Terminal M6
Storage duration 6 months at 25℃
Safety standard IEC62619,UN38.3,MSDS,CE
Communication function RS484/UART/SNMP/Wifi/Bluetooth
PROTECTION
Protection Overcharge protectionOverdischarge protectionOvercurrent protection Shortcircuit protectionOvertemperature protection
AMBIENT
Noise(dB) ＜40dB(1 meter)
Working temperature -20℃～+60℃
Humidity 0～95%(no condensation)
Altitude(m) <3000
DIMENSION
L*W*H( size)mm L405*W483*H178mm L655*W483*H178mm
L*W*H(package size)mm L440*W518*H213mm L690*W518*H213mm
Net Weight(Kg): Approx.35kg Approx.72kg
Gross Weight(Kg): Approx.39kg Approx.78kg

Applications:

◆ UPS
◆ Solar & Wind Power System
◆ Golf Cart
◆ Electric Vehicle , E-bike, E-rickshaw etc.
◆ Lighting



Backup Power Supply LiFePO4 Battery Pack Lithium Iron Phosphate Cell 1

Support and Services:

We offer technical support and services for LiFePO4 Battery Pack, including:

  • Assist with product selection and application
  • Product installation and troubleshooting
  • Product testing and evaluation
  • Product customization
  • Product repair and maintenance





FAQ:

1). Are the batteries GRADE-A,Brand NEW?

Yes, GRADE A + quality. the QR code is intact, Brand new.



2). Are the batteries come with busbars+bolts?

The price come with Bus bars and Bolts , One Battery will come with one set bus bar and bolt ( e.g.,lf buy 4pcs battery,we will send 4pcs cells with 4pcs busbars and 8pcs bolts ) If need more please contact us online.



3).Can you test each battery PRIOR to shipping?

We will test all the battery Voltage and Internal resistance before shipping.



4.) What kind of the package of the cells?

Pack with strong package, each cell into thickness PE foam or bag, then into 5 layers strong carton.



Why choose us?

  • Our team of experts can help you choose the best LiFePO4 batteries for your needs.
  • The scale of the company ranks in the forefront of the industry and has become the preferred manufacturer in the Lifepo4 Battery 48v200ah industry, providing high-quality products and services and advanced system solutions.
  • As a supplier and manufacturer, our prices are very competitive.
  • After years of unremitting efforts and the love and support of the majority of users, our company has become the most competitive manufacturer with high-quality products, honest service and quick work efficiency.
  • Our LiFePO4 batteries are designed to deliver high performance in demanding applications.
  • We combine the world's most advanced innovative technology with customer-centric products and services.
  • Our LiFePO4 batteries are interchangeable with many other LiFePO4 batteries on the market.
  • "Bold innovation, originality and excellence" is our unremitting goal.
  • We offer competitive pricing without compromising on quality.
  • The company takes the standardized quality management system as the standard and introduces the international advanced experience.
