Long Cycle Life Lithium Ion Phosphate Battery 100A Max Charge Current
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
WeChat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Battery Type | LiFePO4 | Max Charge Current | 100A |
|---|---|---|---|
| Max Discharge Current | 100A | Cycle Life | 5000 Times |
| Warranty | 5 Year | Capacity | 100Ah |
| Highlight | Long Cycle Lithium Ion Phosphate Battery,100A Lithium Ion Phosphate Battery,LiFePO4 Long Cycle Battery Pack |
||
Product Description
100AH 200AH Lithium LiFePO4 Rack Mount Battery Wholesale
24V 100AH Lifepo4 Battery Pack, lifepo4 battery pack supplier
Product Description:
Smart LFP series LiFePO4 battery is a high-tech product developed for the requirements of new backup power supply and household renewable energy storage. Built-in intelligent BMS to protect the battery pack at any time and prolong its service life, modular design enables parallel installation for larger power back up.
Features:
Cells cycle times 5000 cycles(+25℃ 0.5C 85% DOD).
Long lifespan: 5 years warranty, 10 years life design.
4U rack-mount chassis design is easy for parallel expansion and
maintenance.
Smart BMS system to optimize the performance.
Communication: RS485/SNMP/Wifi/Bluetooth, Compatible
with different brand of solar inverter and chargers.
All around protection: such as SOC/SOH etc..
High discharge rate currents, suitable for on-grid or off-grid solar
system and other loads.
Maximum of 16 battery packs can be connected in parallel.
With front display to know effectively the status of the batteries.
Technical Parameters:
| MODEL # | LFP 24-100 | LFP 48-50 | LFP 48-100 |
| SPECIFICATION | |||
| Battery Type | LiFePO4 | LiFePO4 | LiFePO4 |
| Battery Model | 25.6V100AH | 51.2V50AH | 51.2V100AH |
| Nominal Capacity(25℃,0.2C)WH | 2560Wh | 2560Wh | 5120Wh |
| Adjustable working voltage(Vdc) | 22.4～29.2V | 44.8～58.4V | 44.8～58.4V |
| Folat Charge Voltage(Vdc) | 28V | 56V | 56V |
| Max.Continuous discharge current(A) | 100 | 100 | 100 |
| Max.pulse discharge current(A) | 150A 1Sec. | 100A 1Sec. | 150A 1Sec. |
| Max.Continuous charge current(A) | 100 | 50 | 100 |
| Cycle life(+25℃ 0.2C 80% DOD) | ＞5000 Cycles | ＞5000 Cycles | ＞5000 Cycles |
| Cell Equalizer Current(A | 0.1～5A Max.(optional) | 0.1～5A Max.(optional) | 0.1～5A Max.(optional) |
| Terminal | M6 | ||
| Storage duration | 6 months at 25℃ | ||
| Safety standard | IEC62619,UN38.3,MSDS,CE | ||
| Communication function | RS484/UART/SNMP/Wifi/Bluetooth | ||
| PROTECTION | |||
| Protection | Overcharge protectionOverdischarge protectionOvercurrent protection Shortcircuit protectionOvertemperature protection | ||
| AMBIENT | |||
| Noise(dB) | ＜40dB(1 meter) | ||
| Working temperature | -20℃～+60℃ | ||
| Humidity | 0～95%(no condensation) | ||
| Altitude(m) | <3000 | ||
| DIMENSION | |||
| L*W*H( size)mm | L405*W483*H178mm | L655*W483*H178mm | |
| L*W*H(package size)mm | L440*W518*H213mm | L690*W518*H213mm | |
| Net Weight(Kg): | Approx.35kg | Approx.72kg | |
| Gross Weight(Kg): | Approx.39kg | Approx.78kg | |
Applications:
◆ UPS
◆ Solar & Wind Power System
◆ Golf Cart
◆Electric Vehicle , E-bike, E-rickshaw etc.
◆ Lighting
FAQ:
Q1: Are you trading company or manufacturer ?
A: We G-Tech Energy company are factory which has over 19 years manufacture experience in Guang Dong,china.
Q2: Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Customized is available.
Q3: How to proceed an order?
A: 1. Let us know your requirements or application. 2. We quote according to your requirements or our suggestions. 3. Client confirms the samples and places deposit for formal order. 4. We arrange the production.
Q4: How do you ship the goods and how long does it take to arrive?
A: We usuallly ship by Fedex. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5: Where can I get the price?
A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we’ll regard your inquiry priority
We provide one-stop battery power solution, including cell selection, battery pack design, PCM/BMS design, battery pack assembly, OEM Packing and after sales service.
