Lithium Iron Phosphate LiFePO4 Battery Pack With 5000 Times Cycle Life

Lithium Iron Phosphate LiFePO4 Battery Pack With 5000 Times Cycle Life

Lithium Iron LiFePO4 Battery Pack

UN38.3 LiFePO4 Battery Pack

Phosphate Lithium Cell Pack

Place of Origin:

China

Brand Name:

OEM

Certification:

UL, CE, UN38.3, MSDS

Model Number:

LFP48-100

Contact Us
Request A Quote
Product Details
Battery Type:
LiFePO4
Capacity:
100Ah
Warranty:
3 Year
Cycle Life:
5000 Times
Energy:
4800WH
Max Charge Current:
100A
Payment & Shipping Terms
Minimum Order Quantity
1
Price
Negotiable
Packaging Details
Carton packing
Product Description

Product Description:

LiFePO4 Battery Pack

Our LiFePO4 battery pack is a Lithium-Iron-Phosphate-Cell-Pack with maximum charge current of 100A and 100Ah capacity. This battery pack is designed to provide a long cycle life of up to 5000 times with a 3 year warranty. It is the perfect solution for those looking for reliable, high performance LiFePO4-Battery. Our LiFePO4-Battery Pack can be charged quickly and safely with maximum Charge-Current of 100A.

The LiFePO4-Battery Pack is designed to be both efficient and reliable, providing high performance and long cycle life. It is also designed to be safe and secure, with advanced safety features that protect the battery from overcharging, discharging and other potential risks. The LiFePO4-Battery Pack is also designed to be lightweight and compact, making it easy to transport and store.

Our LiFePO4-Battery Pack is the perfect solution for those looking for reliable, high performance LiFePO4-Battery. It is the perfect choice for those looking for a long cycle life, high performance and safety. With our LiFePO4-Battery Pack, you can charge quickly and safely with maximum Charge-Current of 100A, and enjoy a long cycle life of up to 5000 times with a 3 year warranty.

Lithium Iron Phosphate LiFePO4 Battery Pack With 5000 Times Cycle Life 0

Features:

  • LFP-Battery-Pack: LiFePO4 Battery Pack
  • LiFePO4-Cell-Pack: Energy: 4800WH, Cycle Life: 5000 Times, Max Charge Current: 100A, Capacity: 100Ah, Battery Type: LiFePO4
  • Lithium-Iron-Phosphate-Cell-Pack: LiFePO4 Battery Pack with 4800WH Energy, 5000 Cycle Life, 100A Max Charge Current and 100Ah Capacity


Technical Parameters:

MODEL # LFP 24-100 LFP 48-50 LFP 48-100
SPECIFICATION
Battery Type LiFePO4 LiFePO4 LiFePO4
Battery Model 25.6V100AH 51.2V50AH 51.2V100AH
Nominal Capacity(25℃,0.2C)WH 2560Wh 2560Wh 5120Wh
Adjustable working voltage(Vdc) 22.4~29.2V 44.8~58.4V 44.8~58.4V
Folat Charge Voltage(Vdc) 28V 56V 56V
Max.Continuous discharge current(A) 100 100 100
Max.pulse discharge current(A) 150A 1Sec. 100A 1Sec. 150A 1Sec.
Max.Continuous charge current(A) 100 50 100
Cycle life(+25℃ 0.2C 80% DOD) >5000 Cycles >5000 Cycles >5000 Cycles
Cell Equalizer Current(A 0.1~5A Max.(optional) 0.1~5A Max.(optional) 0.1~5A Max.(optional)
Terminal M6
Storage duration 6 months at 25℃
Safety standard IEC62619,UN38.3,MSDS,CE
Communication function RS484/UART/SNMP/Wifi/Bluetooth
PROTECTION
Protection Overcharge protectionOverdischarge protectionOvercurrent protection Shortcircuit protectionOvertemperature protection
AMBIENT
Noise(dB) <40dB(1 meter)
Working temperature -20℃~+60℃
Humidity 0~95%(no condensation)
Altitude(m) <3000
DIMENSION
L*W*H( size)mm L405*W483*H178mm L655*W483*H178mm
L*W*H(package size)mm L440*W518*H213mm L690*W518*H213mm
Net Weight(Kg): Approx.35kg Approx.72kg
Gross Weight(Kg): Approx.39kg Approx.78kg


Applications:

The LFP-Battery LiFePO4 Cell Pack is an OEM battery pack that is manufactured by a reputable company in China. It is UL certified and UN38.3 compliant, as well as having MSDS certification, indicating its high quality and reliability. This LiFePO4 Cell Pack is a great choice for those who are looking for an energy-efficient, high-performance battery pack that can provide superior performance with minimal maintenance. It is available in a variety of sizes and capacities, ranging from 100Ah to 4800WH, and can be custom-fit to an individual's needs. It also has a maximum charge current of 100A and is capable of up to 5000 cycles, making it an excellent choice for long-term applications. The price of the LiFePO4 Cell Pack is negotiable and the minimum order quantity is 1.



Support and Services:

LiFePO4 Battery Pack Technical Support and Service

We offer technical support and services for our LiFePO4 Battery Pack product. Our team of highly experienced and knowledgeable engineers, technicians, and customer service representatives are here to help you get the most out of your LiFePO4 Battery Pack.

We provide a wide range of services, including:

  • Troubleshooting and diagnostics
  • Software and firmware updates
  • Product installation and configuration
  • Maintenance and repairs
  • Customer support and advice

If you have any questions or concerns about your LiFePO4 Battery Pack, don't hesitate to contact our customer service team. We are dedicated to providing you with the best possible service and support.



Packing and Shipping:

Packaging and Shipping

LiFePO4 Battery Pack should be packaged in a sturdy cardboard box, with the edges and corners reinforced to protect against damage. It should be cushioned with at least 2 inches of foam or bubble wrap. The battery should be placed in a plastic bag to protect against short circuits. All components of the battery pack should be secured with zip ties.

The shipping label should include the address of the recipient, the shipping date, and the weight of the package. A tracking number should be included if possible. The package should be marked with "Fragile: Handle With Care" to prevent damage during shipping.
