LW-10K Model LiFePO4 Battery Pack 51.2V 200AH with Cell Equalizer Current of 0.1-10AMax. Optional for Fast Charging
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
WeChat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Highlight | 51.2V 200AH LiFePO4 Battery Pack,Fast Charging LiFePO4 Battery Pack |
||
|---|---|---|---|
Product Description
Specification:
| Model | LW-5K | LW-10K |
| Battery Type | LFP | LFP |
| Battery Model | 51.2V100AH | 51.2V200AH |
| Nominal Capacity(25c,0.2C)Wh | 5120Wh | 10.24KWh |
| Adjustable Working Voltage(Vdc) | 40~56.8V | 40~56.8V |
| Max Charge Cut-off Voltage(Vdc) | 58.4V | 58.4V |
| Max.Continuous Discharge Current(A) | 100 | 200 |
| Max.Pulse Discharge Current(A) | 150A(1 sec)configurable | 300A(1 sec)configurable |
| Max.Continuous Charge Current(A) | 100 | 200 |
| Cycle Life(25C 0.2C 80%DOD) | >5000 Cycles | >5000 Cycles |
| Cell Equalizer Current(A) | 0.1~5AMax.(Optional) | 0.1~10AMax.(Optional) |
| Terminal | EES-6mm quick plug terminal | EES-6mm quick plug terminal |
| Storage Duration | 6 months at 25 ℃ | 6 months at 25 ℃ |
| Safety Standard | UN38.3.MSDS.CE | UN38.3.MSDS.CE |
| Communication Function | RS485/CAN(Standard) | RS485/CAN(Standard) |
| Protection | Over charge protection/ Over discharge protection/Ove rcurrent protection/ Short circuit protection/ Over temperature protection |
|
| W*H*D(product size)mm | W500*H600*D165 W415*H715*D250 | |
| Net Weight(Kg) | 46.6 | 90 |
