Line Interactive PWM UPS Power Supply
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
WeChat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Application | PC, Router, POS Machine Communication Processor, Industrial Products | Display | LED Or LCD For Optional |
|---|---|---|---|
| Product Name | Line Interactive UPS, UPS Power Supply For Home, Microtek Home UPS | Type | Line Interactive UPS |
| Wave Form | PWM (DC Mode) | Warranty | 12 Months |
| Highlight | Line Interactive PWM UPS,PWM UPS Power Supply,G TECH PWM UPS |
||
Product Description
Line Interactive UPS 600va to 3000va, UPS power supply for home, microtek home UPS
Line interactive offline UPS V series for home appliances is hot sale Uninterrupted Power Supply Unit, with PWM output and design for home use, including power 500VA/300W, 650VA/360W, 850VA/480W, 1050VA/525W, 1500VA/900W, 3000VA/1800W for option.
Feature:
1. CPU controlled
2. Auto re-starts when AC recovers
3. Silence setup
4. Automatic charging (offline charging)
5. Battery low voltage protection
6. Overload & short circuit protection
7. Wide input voltage range
Application:
Suitable for the PC, router, POS machine communication processor, industrial products which for the enterprises, government, scientific research, traffic, national defense, information and education industries.
UPS Specification:
|
Model # |
VP-500 |
VP-650 |
VP-800 |
VP-1000 |
VP-1200 |
VP-1500 |
||
|
Capacity |
500VA/300W |
650VA/390W |
800VA/480W |
1000VA/600W |
1200VA/720W |
1500VA/900W |
||
|
AVR |
No (can add) |
3 steps of AVR, CPU controlled |
||||||
|
INPUT |
||||||||
|
Input voltage range |
220V:175~265±5Vac |
220V:145~290Vac±5Vac |
||||||
|
110V: 90~132±5Vac |
110V: 85~150Vac±5Vac |
|||||||
|
Input frequency range |
50Hz / 60Hz (Auto sensing) |
|||||||
|
OUTPUT |
||||||||
|
Output voltage range |
220V: 175~265±5Vac |
220V:200~255Vac |
||||||
|
110V: 90~132±5Vac |
110V: 102~132Vac |
|||||||
|
Output frequency (DC mode) |
50±0.5Hz / 60±0.5Hz |
|||||||
|
Wave form |
PWM (DC Mode) |
|||||||
|
Transfer time |
Typical 2~6ms, Max.10ms. |
|||||||
|
BATTERY |
||||||||
|
QTY & capacity of battery |
1 pc*12V4.5Ah |
1 PC*12V7Ah |
1 pc*12V9Ah |
2 pcs*12V7Ah |
2 pcs*12V7Ah |
2 pcs*12V9Ah |
||
|
Charging period |
4~6 hours recover to 90% capacity |
|||||||
|
PROTECTION & FUNCTION |
||||||||
|
PROTECTION |
1. Battery low voltage protection |
|||||||
|
FUNCTION |
1. Auto re-starts when AC recovers |
|||||||
|
MANAGEMENT |
||||||||
|
RJ45/11 & USB |
Refer to customers' requires. |
|||||||
This series of Line interactive offline UPS V series is specifically designed for PC. It applies CPU integrated control technology and SMD(Surface Mount Deices)technology, which makes it perform satisfactorily and pleasing to the eye. It is an indispensable companion of PC, router and POS machines.
