Place of Origin:
China
Brand Name:
G-Tech
Certification:
CE ROHS
Model Number:
V-
2KVA Modified Sine Wave PWM UPS
Computer Offline UPS 650va 850va 1000va 1500va High Quality Modified Sine Wave with AVR CE
| MODEL | V-600 | V-800 | V-1000 | V-1500 | V-2000 | V-3000 |
|---|---|---|---|---|---|---|
| Capacity | 600VA/360W | 800VA/480W | 1000VA/600W | 1500VA/900W | 2KVA/1200W | 3KVA/1800W |
| INPUT | ||||||
| Input Voltage | 220/230/240VAC | |||||
| Intput Voltage Range | 145-290Va | 175-275Vac | ||||
| Frequency Range | 45-65Hz | |||||
| Output Voltage | 220/230/240Vac | |||||
| Output Voltage Range | 200-255Vac | |||||
| Output Frequency | 60±0.5Hz or 50±0.5Hz(Auto Sensing) | |||||
| Output Wave Form | PWM(Batt.Mode) | |||||
| Transfer Time | Typical(2-6ms),10ms max | |||||
| BATTETRY | ||||||
| Qty.& Capacity of Battery | 12V/7AH*1pc | 12V/9AH*1pc | 12V/7AH*2pcs | 12V/9AH*2pcs | 12V/7AH*4pcs | 12V/9AH*4pcs |
| Charging Period | 4-6hours recover to 90% capacity | |||||
| PROTECTION | ||||||
| Full Protection | Low Voltage &overload&short circuit protection | |||||
| PHYSICAL | ||||||
| Net Weight(kg) | 4.6 | 5.5 | 9.5 | 11.5 | 18 | 20 |
| Unit Dimensions(mm) | 305*85*140 | 350*120*188 | 340*110*265 | |||
| ENVIRONMENT | ||||||
| Environment of Performance | Tempreture 0℃-40℃,Humidity 20%-90% | |||||
| Noise level | ≤40dB(1m) | |||||
| MANAGEMENT | ||||||
| LCD or LED,RJ45/11&USB | Option | |||||
