Place of Origin:
China
Brand Name:
G-Tech
Certification:
CE,Rohs,ISO
Model Number:
SL
Field of application
Applicable to household PC, office euquipment in enterprise and institution, small communication switchborad and server, LAN device,
commerical POS machines, small workstation and its peripheral equipment, banking terminal, ATM system and so on.
Feature
2 CPU Controlled
Pure Sine Wave output
Compatible with generator
Automatically transferred to Batt.Mode when input over/low voltage
Connect to external battery for long power supply
RJ11/45, RS232/USB (Optional)
Tower/Rank Mountable type(Optional)
Slience Running
output Overload and short circut protection
Specifications
Model |
SL-1.5K |
||||
Capacity | 1500VA/1050W | ||||
Display |
LCD/LED(Optional) | ||||
AC Mode |
|||||
Input |
|||||
Voltage |
145-275VAC |
||||
Frequency |
45-65Hz |
||||
Output voltage |
200-240VAC |
||||
Inverter Mode |
|||||
Output voltage |
220V±5% |
||||
Output Frequency |
50±0.5Hz |
||||
Power Factor |
0.7 |
||||
Output wave form |
Pure Sine Wave |
||||
Transfer Time |
Typical 2-6ms, 10ms Max |
||||
Overload capacity |
if 110%, then shut down within 60sec; if 120%, then shut down within 5 sec. |
||||
Battery |
Sealed maintenance-free lead-acid batteries |
||||
DC Voltage |
24VA | ||||
Qty & capacity of Battery |
12V/9AH*2 |
||||
Physical | |||||
Net Weight(kg) | 25.6 | ||||
Dimension(mm) | 405*145*220 | ||||
USB&RS232 | Optional |
Founded In the early 2005, as an UPS/Inverter/VRLA Battery Manufacturer on the market, G-Tech has worked closely with his customers and helped them boost their business for more than 14 years.
Now, we are looking forward to exploring and discovering more opportunities with our customers, and move on to the next 30 years of successful business.
