xProduct Details
| Material | Metal/ABS | Colour | Customized |
|---|---|---|---|
| Warranty | 2 Years | Wave Form | Modified Sine Wave |
| Output | AC 220V | Protection | Overload And Short Circuit Protections |
| Display | LCD/LED Optional | Capacity | 300W-3000W |
| Highlight | pure sine wave inverter for home,pure sinewave inverters |
||
Product Description
Car power inverter,1500W 2400A PIV series,Modified Sine Wave,AC220V,50/60Hz
ART-P series,PWM wave and rated power from 300W to 3000W, designed to meet different requirements in the middle market. Power supply by converting DC 12V/24V/48V(for example, batteries of cars, ships and accumulator etc.) to AC 220V, and suitable for electrical equipment less than 3000W(e.g. Cellphone. Laptop, and solar power system etc.)
Feature:
*Design of aluminum case ensures its excellent cooling ability and sturdiness, also extending service life
*Car cigarette lighter wire and clip wire(optional)for using in car or be used for battery.
*USB interface(optional); Two LED lights for showing the working or protecting status; Button switch to control inverter
*Can start up special load such as refrigerators, air-conditioners, etc.
Specification:
| Model | PIV2400A |
| Output voltage | AC220V |
| Rated power | 1500w |
| Peak power | 2400w |
| Output wave Form |
Modified Sine Wave |
| Frequency | 50/60Hz |
| USB | DC 5V 1A |
| No-load current | <0.4A( input 12.5V) |
| Working Voltage |
DC 12V |
| Voltage range | 15.5-15V |
| Battery low Voltage alarm |
10.5V |
| Battery low Voltage protection |
10V
|
| Battery Overvoltage Protection |
15.5V
|
| Maximum Efficiency |
>85% |
| NW.(kg) | 2.2 |
|
Dimension (mm) |
260*440*85 |
| Size/CTN(mm) | 325*440*320 |
| GW(kg) | 11.8 |
| Quantity/CTN | 4PCS |
Product specifications are subject to change without notice.
