Customized Modified Sine Wave Car Inverter PIV Series Optional LCD / LED Indicators
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
WeChat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Metal/ABS | Warranty | 2 Years |
|---|---|---|---|
| Output | AC 220V | Colour | Customized |
| Display | LCD/LED Optional | Wave Form | Modified Sine Wave |
| Protection | Overload And Short Circuit Protections | Capacity | 1500W-3000W |
| Indicators | LCD Or LED | ||
| Highlight | pure sine wave inverter home depot,pure sinewave inverters |
||
Product Description
Car power inverter, 2100W 3500A PIV series,Modified Sine Wave,AC220V,50/60Hz
PIV series power inverter, have superior load capacity and are particularly for start up inductive load. Also, Various functions can be customized according to the needs of different markets. Based on the basic inverter function, the piv series power inverter can expand other additional functions according to customer requirement or customize the solution for customer specific application environment. Such as LCD display/LED display or AC charger.
Features:
1.Excellent start-up performance, perfect for high-power appliances such as air conditioners, refrigerators, washing machines, etc.
2.High efficiency conversion, negligible no-load current, more energy saving.
3.Optional LCD or LED indicators, showing the working state of inverters directly.
4.Multistage automatic temperature control fan, better ventilation, less noise.
5.It has perfect protection over situable like, input overvoltage and undervoltage, output overload, short circuit, and over temperature.
6.5V/1A USB port.
Specification:
| Model | PIV3500A |
| Output voltage | AC220V |
| Rated power | 2100w |
| Peak power | 3500w |
| Output wave Form |
Modified Sine Wave |
| Frequency | 50/60Hz |
| USB | DC 5V 1A |
| No-load current | <0.4A( input 12.5V) |
| Working Voltage |
DC 12V |
| Voltage range | 15.5-15V |
| Battery low Voltage alarm |
10.5V |
| Battery low Voltage protection |
10V
|
| Battery Overvoltage Protection |
15.5V
|
| Maximum Efficiency |
>85% |
| NW.(kg) | 3 |
|
Dimension (mm) |
360*180*85 |
| Size/CTN(mm) | 425*440*320 |
| GW(kg) | 16.2 |
| Quantity/CTN | 4PCS |
Product specifications are subject to change without notice.
