MPPT Charger 5KW Pure Sine Wave Inverter For Solar Home Use

MPPT Charger 5KW Pure Sine Wave Inverter For Solar Home Use

5KW Pure Sine Wave Inverter

5KW 1500w pure sine wave inverter

pure sine wave inverter home depot

Place of Origin:

China

Brand Name:

G-tech

Certification:

CE/RoHS/ISO

Model Number:

MP MPS Series

Contact Us
Request A Quote
Product Details
Material:
Metal/ABS
Output:
220V/230V/240VAC
Color:
Customized
Display:
LCD/LED Optional
Wave Form:
Pure Sine Wave
Protection::
Overload And Short Circuit Protections
Capacity:
1500W-3000W
Remote Control:
Support
Payment & Shipping Terms
Minimum Order Quantity
1PCS
Price
Negotiation
Packaging Details
Carton
Delivery Time
30 work days
Payment Terms
L/C, T/T, Western Union
Supply Ability
10,000PCS
Product Description

Inverter Home 5KW Sine Wave Power Inverter For Solar Home Use With Solar Controller MPPT Charger, Wall Mounted

300W 500W 1000W 3KW 5KW Pure Sine Wave Inverter for solar home use with solar controller MPPT PWM charger





MP SERIES solar inverter for home use, minimum 1000W MAX 6KW

Model #   1012 1024 2012 2024 3024 3048 4048 5048 6048
Capacity 1000W 1000W 2000W 2000W 3000W 3000W 4000W 5000W 6000W
DISPLAY
Indicator panel LCD display
AC MODE
Input voltage 160~265±5Vac
Input frequency 45~65Hz
Output voltage 160~265±5Vac
Efficiency 96%(AC Mode)
INVERTER MODE
No load current & power 0.6A/7.2W 0.6A/14.4W 0.8A/9.6W 0.7A/16.8W 1A/24W 0.7A/33.6W 0.7A/33.6W 0.8A/38.4W 0.8A/38.4W
THD 3%(linear load)
Output voltage 230Vac
Output frequency 50±0.1Hz/60±0.1Hz(Auto sensing)
Output wave form Pure sine wave
Transfer time 10ms(Typical)
Efficiency 80%(DC Mode)
Overload capbility (100%<Load<120%)±10%: Auto shutdown in 2 mins.
(120%<Load<140%)±10%: Auto shutdown in 60 secs.
(140%<Load)±10%: Auto shutdown in 20 secs.
Overcurrent protection System shuts down auotomatically within 20ms.
Output short circuit protection Yes
BATTERY
DC voltage 12V 24V 12V 24V 24V 48V 48V 48V 48V
Battery type 8 types of battery
AC charging current 5A/10A/20A/30A/45A/(60A) Max.
PHYSICAL
Net weight (1pc, kg) 20 20.0 23.0 23.0 27.1 27.1 30.8 34.2 40.5
Unit dimension (L*W*H) 526*277*215mm
ENVIRONMENT
Environment Temperature 0~40℃, Humidity 20%~90%
Noise Level 40dB(1m)
Altitude 1000m( Altitude exceeds 1000m, full power can't reach)
*Product specifications are subject to change without further notice.



MPPT Charger 5KW Pure Sine Wave Inverter For Solar Home Use 0



Model # XL-600 XL-800 XL-1000 XL-1200 (12V/24V)
Capacity 600VA/500W 800VA/640W 1000VA/800W 1200VA/1000W
Power factor 0.8
INPUT
Input voltage range Inverter mode: 100~290Vac±5Vac
UPS mode: 145~275Vac±5Vac
Input Frenquency 45~65Hz
OUTPUT
Output voltage range Inverter mode: 150~255Vac±5Vac
UPS mode: 203~238Vac±5Vac
Output frequency 50Hz ±0.1Hz (DC mode)
Wave form Pure sine wave (DC Mode)
Transfer time <10ms.
BATTERY
Charging current(AC) 10A/20A/Max.
Type of battery(optional) GEL/ Sealed lead acid/ Open lead acid
PHYSICAL
Unit dimension (mm) 290*255*120
Net weight for XL Series(KG) 7.6 9.8 10.8 12.2
ENVIRONMENT
Environment Temperature 0~40℃, Humidity 20%~90%
Noise Level 40dB(1m)
*Product specifications are subject to change without further notice.



MPPT Charger 5KW Pure Sine Wave Inverter For Solar Home Use 1

Factory Profile:

G-tech Power Co., Ltd. was established in 2002, located at Foshan, Guangdong province. We are a professional manufacturer of high quality UPS (Uninterruptible Power Systems) in China. We specialize in developing, manufacturing and operating the most reliable, manageable and the safest UPS, inverter and AVR (voltage regulator) products.



The factory covers a working area of nearly 20,000 square meters, has more than 500 professional staff (including 30 R&D personnel) and 33 sets of fully automatic SMT lines, more than 10 sets of automatic insertion equipment, ICT PCB testing equipment, ATE automatic testing center and aging workshop for all products.



OEM services are provided for customers in many areas, such as South America, Europe, Russia, India, Africa and some other countries and regions. We are always qualifying ourselves in order to meet the requirements of customers, and we gain more repeat orders and admiration from them.

  • MPPT Charger 5KW Pure Sine Wave Inverter For Solar Home Use 2MPPT Charger 5KW Pure Sine Wave Inverter For Solar Home Use 3
