Uninterruptible Power Station Mini DC UPS Overload Protection

Uninterruptible Power Station Mini DC UPS Overload Protection

Uninterruptible Mini DC UPS

Reverse Polarity Protection Mini DC UPS

Uninterruptible UPS Overload Protection

Place of Origin:

China

Brand Name:

G-Tech

Certification:

CE ROHS ISL UL

Model Number:

ECO

Contact Us
Request A Quote
Product Details
Battery Capacity:
5Ah-100Ah
Charging Voltage:
100V-240V
Working Temperature:
0℃~+40℃
Product Name:
Mini DC UPS
Charging Period:
2~3Hours
Protection:
Overload/Short Circuit/Over Temperature/Reverse Polarity
Payment & Shipping Terms
Minimum Order Quantity
1 pcs
Price
Negotiation
Packaging Details
Carton packing
Delivery Time
7-25workdays
Payment Terms
L/C, T/T, Western Union
Supply Ability
1000000pcs
Product Description

Product Description:

ECO Mini Uninterruptible Power Unit (Mini DC UPS)

ECO Mini Uninterruptible Power Unit (Mini DC UPS) is a reliable, compact and cost effective power solution. It is designed to provide continuous power to your devices in the event of power cuts or other power supply interruptions. It features advanced protection against overload, short circuit, over temperature and reverse polarity. With its 0℃~+40℃ working temperature range, this device offers great protection for your devices.

Mini DC UPS is available in 5Ah to 100Ah battery capacity and can be recharged within 2-3 hours. It is a perfect choice for critical applications, offering protection against power failure and ensuring continuous power supply. It is ideal for both commercial and residential applications.

Uninterruptible Power Station Mini DC UPS Overload Protection 0

Features:

  • Product Name: Economic Mini Uninterruptible Power Station (ECO Mini Uninterruptible Power Unit; Economic Mini Uninterruptible Power Module)
  • Charging Voltage: 100V-240V
  • Charging period: 2~3Hours
  • Battery Capacity: 5Ah-100Ah
  • Working Temperature: 0℃~+40℃
Specification:



Model

(ECO)



212



312



412



1248P



412P



418



418PRO



430PRO

INPUT
Input Voltage 100-240Vac
Output
DC Output Voltage (optional)



5V/7.5V/9V/12V

(POE)





12V&48V

(POE)





9V/12V &

15V/24V

(POE)



5V+USB 2A

9V/12V 1A

15V/24V 0.5A

( POE )



5V+USB 2A

9V 2A

12V 2A

15V/24V 1A

( POE )



Voltage Select Choosing through the slide switch

Output

Power

12W

12W&24W

(total 36W)

12W&48W

(total 60W)

18W 30W
Transfer Time 0 ms
Battery
Battery Type Lithium battery Lead Acid Lithium battery LiFePo4
Capacity

4400

mah

6600mah 8800mah

12v/2.3Ah

*1PC

8800mah 7200mah
Cycle life           300 cycles 1000cycles
Charge
Charging Period Typical: 2-3 Hours
Physical



Unit Dimension

(mm)





165*105*26









268*144*51





108*183*29





159*108*28

Net Weight

(kg)



0.28



0.36



1.6



0.62



0.4

Enviroment
Performance Temperature degree Celsius
Noise level Less than 40dB


Applications:

G-Tech ECO Mini Uninterruptible Power Unit (UPS) is an ideal choice for a variety of applications. It is suitable for use in various scenarios such as offices, homes, retail stores, schools, and more. Its powerful 5 Ah to 100 Ah rechargeable battery ensures long lasting power supply in case of power outages. The mini UPS can be conveniently charged with a voltage of 100V to 240V, and the charging time is just 2 to 3 hours. The unit also offers superior protection against overload, short circuit, over temperature, and reverse polarity. Plus, its working temperature range is from 0℃ to +40℃, allowing it to be used in a wide variety of environments.

G-Tech ECO Mini Uninterruptible Power System (UPS) will provide your business or home with reliable and uninterrupted power supply no matter where you are. It is not only a great energy saver, but also a great safety feature. With its advanced protection functions, you can rest assured that your data and equipment are always protected against power outages. Plus, its compact and lightweight design makes it easy to transport and install. With G-Tech ECO Mini Uninterruptible Power Unit (UPS), you can be sure of a reliable and efficient power supply.



Customization:

G-Tech Eco Mini Uninterruptible Power Supply

G-Tech ECO Mini Uninterruptible Power Supply is a reliable and economic mini uninterruptible power station with multiple protection functions. It features a working temperature of 0℃ to +40℃, charging voltage of 100V-240V and battery capacity of 5Ah-100Ah. This mini UPS features over-load, short circuit, over temperature and reverse polarity protection.



Packing and Shipping:

Packaging and Shipping

Mini DC UPS products are securely packaged to prevent any damage during shipping. Mini DC UPS products are shipped in packaging that is specifically designed to protect the product from damage caused by shipping, such as vibration, shock, and weather. All packaging materials are recyclable and/or reusable.

The products are shipped in cardboard boxes that are designed to fit most standard shipping sizes. The boxes are also designed to be easy to open and close. Once the product is packaged, it is placed in a secure shipping container to protect it from any damage during transit.

All Mini DC UPS products are shipped in accordance with international shipping regulations. All products are shipped with full insurance coverage so that any damage caused during shipping can be quickly and easily resolved.

Uninterruptible Power Station Mini DC UPS Overload Protection 1

FAQ:

Q: What is Mini DC UPS?
A: Mini DC UPS is a power supply device manufactured by G-Tech, model number ECO, which is made in China. It is used to provide backup power in case of short-term power outages.
Q: What are the features of Mini DC UPS?
A: Mini DC UPS features quick power-on and off, long battery life, and it is highly reliable and efficient.
Q: How long does the battery of Mini DC UPS last?
A: The battery of Mini DC UPS can last up to 3 hours, depending on the load.
Q: What is the input voltage range of Mini DC UPS?
A: The input voltage range of Mini DC UPS is 100-260VAC.
Q: What kind of protection does Mini DC UPS provide?
A: Mini DC UPS provides overvoltage, undervoltage, short-circuit, and over-temperature protection.
Uninterruptible Power Station Mini DC UPS Overload Protection 2
