ECO Mini Uninterruptible Power System 100V-240V 5Ah-100Ah
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
WeChat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Battery Capacity | 5Ah-100Ah | Charging Period | 2~3Hours |
|---|---|---|---|
| Product Name | Long Mini DC UPS | Protection | Overload/Short Circuit/Over Temperature/Reverse Polarity |
| Working Temperature | 0℃~+40℃ | Charging Voltage | 100V-240V |
| Highlight | ECO Mini Uninterruptible Power System |
||
Product Description
Product Description:
Introducing Long Mini DC UPS – an economic mini uninterruptible power module that provides reliable power backup solutions for a wide range of applications. This product is designed to deliver safe and uninterrupted power supply, even in the event of a power outage. Featuring a charging voltage of 100V-240V and a charging period of 2~3Hours, this mini uninterruptible power station is perfect for those who need a reliable and cost-effective power backup solution. Long Mini DC UPS also comes with an array of protection features such as Overload/Short Circuit/Over Temperature/Reverse Polarity, ensuring maximum safety and reliability. With a wide range of battery capacity options from 5Ah-100Ah, Long Mini DC UPS is the perfect choice for those who need a dependable and efficient power backup solution.
Features:
- Product Name: Long Mini DC UPS
- ECO Mini Uninterruptible Power System
- ECO Mini Uninterruptible Power Source
- Economic Mini Uninterruptible Power Station
- Charging period: 2~3Hours
- Charging Voltage: 100V-240V
- Protection: Overload/Short Circuit/Over Temperature/Reverse Polarity
- Working Temperature: 0℃~+40℃
Technical Parameters:
Specification:
|
Model |
ECO Plus | |||||||
| 212 | 415 | 415P | 430P | 430M | 430S | 860 | 1660 | |
| Input Voltage | 100-240Vac | |||||||
| Output | ||||||||
|
DC output Volatge (optional ) |
USB 1.5A 9/12V 1A |
5V+USB 2A 9V/12V 1A 12V 1A |
5V USB 2A 9V/12V 1A 15V/24V 0.5A (POE) |
5V USB 2A 9V/12V 2A 15V/24V 1A (POE) |
5V USB 2A 9V/12V 2A 12Vx4 2A |
5V USB 2A 9V/ 12Vx4 2A Solar input |
5V USBx2 2A 9V/ 12V 2A 15V/24V(POE) 1A 12Vx4 5A Solar input 2A |
|
| Voltage Select | Choosing through the slide switch | |||||||
| Output Power(max) | 12W | 15W | 30W | 60W | ||||
|
Transfer Time |
0 ms | |||||||
| Battery | ||||||||
| Type | Lithium battery | |||||||
|
Qty & Capacity |
6700mAh | 8800mAh | 2200mAhX8 | 2200mAhX16 | ||||
|
Charging Period |
1-2 hours | 2-3 hours | 4-5 hours | |||||
| Physical | ||||||||
|
Dimension (mm) |
141.5*84.5*35 | 180*106*29 | 258*152*46 | |||||
|
Net Weight(kg) |
0.3 | 0.4 | 0.94 | 1.28 | ||||
| Environment | ||||||||
| Performance | Temperature 0℃~40℃ ; Humanity20%~90% | |||||||
| Noise level | Less than 40dB | |||||||
Product specifications are subject to change without notice.
Applications:
The ECO Mini Uninterruptible Power System (UPS) from ODM is designed to provide reliable and economic power backup in a wide variety of applications. This Mini DC UPS features a reliable protection system against overload, short circuit, over temperature, and reverse polarity. It also offers a wide range of battery capacities from 5Ah to 100Ah, with a fast charging period of 2 to 3 hours. This product is suitable for working environments within a temperature range of 0℃ to +40℃. It is an ideal choice for those who need a reliable, economic, and long-lasting Mini Uninterruptible Power Source (UPS).
Packing and Shipping:
The Mini DC UPS comes packaged in a small box that is designed to protect the unit during shipping. The box contains the unit, an AC adapter, and all necessary cables and manuals. The box should be properly sealed to ensure the box remains secure during transit.
The Mini DC UPS should be shipped using a reliable and safe shipping service. We recommend using a service that offers tracking information and insurance to ensure that the package is delivered safely and on-time. The package should be marked as fragile to ensure proper handling during transit.
FAQ:
- Q1: What is Mini DC UPS?
- A1: Mini DC UPS is an uninterruptible power supply manufactured by ODM, with model number ECO, and made in China.
- Q2: What is the purpose of Mini DC UPS?
- A2: Mini DC UPS provides a backup power supply and power protection for your equipment from power surges and blackouts.
- Q3: What are the features of Mini DC UPS?
- A3: Mini DC UPS is designed with multiple features, including wide input voltage range, high efficiency, high frequency isolation transformer, and long backup time.
- Q4: What are the applications of Mini DC UPS?
- A4: Mini DC UPS is widely used in industrial automation, medical equipment, electric power, communications, and other areas.
- Q5: How to maintain Mini DC UPS?
- A5: To ensure the stability and long service life of Mini DC UPS, please clean the dust regularly, and check the external power supply and internal components regularly.
