12W-60W Mini DC UPS Overload/Short Circuit/Over Temperature/Reverse Polarity Protection
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
WeChat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Charging Period | 2~3Hours | Working Temperature | 0℃~+40℃ |
|---|---|---|---|
| Battery Type | Lithium | Output Power | 12W-60W |
| Protection | Overload/Short Circuit/Over Temperature/Reverse Polarity | Product Name | DC UPS |
| Highlight | 60W Mini DC UPS,Overload Protection Mini DC UPS |
||
Product Description
Product Description:
The Economic Mini Uninterruptible Power Station (ECO Mini UPS) is a powerful, reliable, and cost-effective DC UPS. It has a lithium battery type, and is able to charge in only 2-3 hours. With a working temperature from 0℃ to +40℃, it is suitable for all environments. This mini uninterruptible power system is able to provide users with overload/short circuit/over temperature/reverse polarity protection, making it a reliable and safe choice. The Economic Mini Uninterruptible Power Backup System (ECO Mini UPS) is the ultimate choice for those looking for an economical and reliable solution to their power backup needs.
Technical Parameters:
Specification:
|
Model |
ECO Plus | |||||||
| 212 | 415 | 415P | 430P | 430M | 430S | 860 | 1660 | |
| Input Voltage | 100-240Vac | |||||||
| Output | ||||||||
|
DC output Volatge (optional ) |
USB 1.5A 9/12V 1A |
5V+USB 2A 9V/12V 1A 12V 1A |
5V USB 2A 9V/12V 1A 15V/24V 0.5A (POE) |
5V USB 2A 9V/12V 2A 15V/24V 1A (POE) |
5V USB 2A 9V/12V 2A 12Vx4 2A |
5V USB 2A 9V/ 12Vx4 2A Solar input |
5V USBx2 2A 9V/ 12V 2A 15V/24V(POE) 1A 12Vx4 5A Solar input 2A |
|
| Voltage Select | Choosing through the slide switch | |||||||
| Output Power(max) | 12W | 15W | 30W | 60W | ||||
|
Transfer Time |
0 ms | |||||||
| Battery | ||||||||
| Type | Lithium battery | |||||||
|
Qty & Capacity |
6700mAh | 8800mAh | 2200mAhX8 | 2200mAhX16 | ||||
|
Charging Period |
1-2 hours | 2-3 hours | 4-5 hours | |||||
| Physical | ||||||||
|
Dimension (mm) |
141.5*84.5*35 | 180*106*29 | 258*152*46 | |||||
|
Net Weight(kg) |
0.3 | 0.4 | 0.94 | 1.28 | ||||
| Environment | ||||||||
| Performance | Temperature 0℃~40℃ ; Humanity20%~90% | |||||||
| Noise level | Less than 40dB | |||||||
Product specifications are subject to change without notice.
