12W-60W Mini DC UPS Overload/Short Circuit/Over Temperature/Reverse Polarity Protection

12W-60W Mini DC UPS Overload/Short Circuit/Over Temperature/Reverse Polarity Protection

60W Mini DC UPS

Overload Protection Mini DC UPS

Place of Origin:

China

Brand Name:

OEM

Certification:

CE, ISO,SGS

Model Number:

DC

Contact Us
Request A Quote
Product Details
Charging Period:
2~3Hours
Working Temperature:
0℃~+40℃
Battery Type:
Lithium
Output Power:
12W-60W
Protection:
Overload/Short Circuit/Over Temperature/Reverse Polarity
Product Name:
DC UPS
Payment & Shipping Terms
Minimum Order Quantity
100
Price
negotiation
Packaging Details
carton
Delivery Time
20~25days
Payment Terms
L/C, T/T, Western Union
Supply Ability
200000 pcs per month
Product Description

Product Description:

The Economic Mini Uninterruptible Power Station (ECO Mini UPS) is a powerful, reliable, and cost-effective DC UPS. It has a lithium battery type, and is able to charge in only 2-3 hours. With a working temperature from 0℃ to +40℃, it is suitable for all environments. This mini uninterruptible power system is able to provide users with overload/short circuit/over temperature/reverse polarity protection, making it a reliable and safe choice. The Economic Mini Uninterruptible Power Backup System (ECO Mini UPS) is the ultimate choice for those looking for an economical and reliable solution to their power backup needs.

Technical Parameters:

Specification:



Model

ECO Plus
212 415 415P 430P 430M 430S 860 1660
Input Voltage 100-240Vac
Output

DC output Volatge

(optional )

USB 1.5A

9/12V 1A

5V+USB 2A

9V/12V 1A

12V 1A

5V USB 2A

9V/12V 1A

15V/24V

0.5A (POE)

5V USB 2A

9V/12V 2A

15V/24V

1A (POE)

5V USB 2A

9V/12V 2A

12Vx4 2A

5V USB 2A

9V/ 12Vx4 2A

Solar input

5V USBx2 2A

9V/ 12V 2A

15V/24V(POE) 1A

12Vx4 5A

Solar input 2A

Voltage Select Choosing through the slide switch
Output Power(max) 12W 15W 30W 60W

Transfer

Time

0 ms
Battery
Type Lithium battery

Qty &

Capacity

6700mAh 8800mAh 2200mAhX8 2200mAhX16

Charging

Period

1-2 hours 2-3 hours 4-5 hours
Physical

Dimension

(mm)

141.5*84.5*35 180*106*29 258*152*46

Net

Weight(kg)

0.3 0.4 0.94 1.28
Environment
Performance Temperature 0℃~40℃ ; Humanity20%~90%
Noise level Less than 40dB

Product specifications are subject to change without notice.
